Bachmann Twist 1x socket, 2x Custom Module (931.133) black matt
The Bachmann Twist 931.133 1x socket, 2x custom module in black matt is a socket unit for office, lounge and kitchen. Thanks to the compact design and low installation depth, it is integrated into desks or kitchen worktops to save space.
Bachmann Twist 1x socket, 2x Custom Module (931.133) in black matt
The Bachmann Twist 1x socket, 2x custom module (931.133) in matt black is a socket unit for office, lounge and kitchen. Thanks to the compact design and low installation depth, it is integrated into desks or kitchen worktops to save space. The power line is routed close to the housing so that the installation depth is only approx. 40 mm - installation via drawers is thus easily possible.
Due to the matt black finish, the Bachmann TWIST 931.133 fits into modern as well as organic, lively form and color concepts. Clever is the closure: after use, the cover is rotated - the sockets disappear underneath.
Key features Bachmann Twist 1x socket, 2x Custom Module 931.133
- Very small installation depth (about 40 mm)
- Dimensions (HxØ): 42.5x115 mm
- Installation diameter 105 mm, installation depth 40 mm
- Plate thickness: 20 to 40 mm
- Space-saving cable routing
- Material cover: metal
- Material socket: plastic
- 1 x socket with child protection
- 2x custom module
- Supply line: 0.2 m
- Plug: Wieland GST18i3
- Incl. Wire end ferrule and mounting plug
- Easy and quick installation
- Finish: black similar to RAL 9005, semi-gloss 30 GE
- Integrated water drainage
- IP20 dustproof
- Splashproof in closed condition
[pdf]
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
