Bachmann STEP ALU automatic switchoff with GST18 (906.18823)
Bachmann STEP ALU automatic switch-off socket with GST18 (906.18823) is the successor to 906.005 and a modular socket unit with button connection for connection to the Bachmann module 917.060.
Socket strip with automatic switch-off
The Bachmann socket strip STEP ALU (906.18823) automatic switch-off with GST18i3 is a simple, modular electrification set. Several socket units can be connected to each other as a modular system. Bachmann STEP is primarily designed as a simple electrification unit for the workplace. Permanently installed devices such as PCs, monitors, printers, etc. can be connected to Bachmann STEP. Bachmann STEP power strips have a power input and a power output, each integrated in the end caps on the front. The built-in GST18 plug connectors from Wieland are particularly tried and tested connectors for office use and have the appropriate coding and plug latching in accordance with the applicable standard.
Key features Bachmann STEP ALU socket unit with GST18
- Length approx. 280 mm
- Width 52 mm
- 1x Automatic switch-off with socket
- 1x button connection with 0.5 m cable and plug connector
- For connection to module 917.060
- Power input: GST18i3 plug black
- Power output: GST18i3 socket black
- Incl. Plug latching
- Silver aluminum profile, black sockets
- Infeed directly at the power connection with device cable or via infeed modules
- Linking of the power strips to one another using device extensions
- Optional assembly of the strips with modules
- Power input and output with Wieland GST18 plug-in system
- Mounting option on T- Nut profiles and stand profiles from different suppliers
- Easy assembly with adapted brackets (ESD-capable)
- Compact dimensions and stable housing
- Successor of 906.005
| Product sheet: |  [pdf] |
|---|---|
| Technical drawing: | [pdf] |
| RoHS / REACH: | [pdf] |
| Others: | [pdf] |
| Installation manual: | [pdf] |
| Warning/safety instructions: | [pdf] |
| Old model no.: | 906.005 |
| Packaging dimensions (LxWxH in mm): | 282 x 52 x 44 |
| Scope of delivery: | 1 x Bachmann Steckdosenleiste |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| Number of sockets: | 1 |
| color: | Black |
| Land: | Germany |
| screw-on: | Yes |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
