Bachmann STEP ALU 2x socket with USB, 2x custom module (906.09838)

Double socket with custom module inserts and USB charger

The Bachmann STEP ALU socket strip (906.09838) is a modular electrification set with a 52 mm aluminum profile height. It is a simple and flexible solution in which several socket units can be connected to one another. The STEP ALU socket strip has two black safety sockets and one USB double charger. This allows various devices such as PCs, monitors, printers, etc. to be connected and charged at the same time via USB. In addition, the socket strip offers space for two custom modules that can be individually designed. The Custom Module inserts can either be empty or equipped with specific functions or connectors, depending on the user's needs.
Power is supplied via a current input and output that are equipped with the tried and tested GST18 connector from Wieland. These connectors are particularly suitable for office use and comply with the current standards for coding and connector locking. Thanks to the modular design and the possibility of individually assembling the modules, the Bachmann STEP system offers a flexible and adaptable solution for power distribution in office workplaces.

Key features Bachmann STEP ALU 906.09838

• Height bar: 52 mm
• 1 x USB double charger 5V DC / 3.1A
• 2 x socket outlets with earthing contact, black
• 2 x custom module inserts
• Maximum 16A / 230V~ / 3,680W
• IP20 degree of protection (protection against contact, dust, water)
• Aluminium profile silver, sockets black
• Power input: GST18i3 plug black
• Power output: GST18i3 socket black
• Incl. Connector latching
• Compact dimensions and stable housing
• Mounting option on T-slot profiles and stand profiles from different suppliers
• Easy mounting with adapted brackets (ESD -capable)
• Power input and output with Wieland GST18 connector system
• Optional assembly of the strips with modules
• Linking of the power strips to one another using device cables ;negated
• Infeed directly at the power connection with device cable or via feed-in modules
• Successor to 906.0229

Diverse mounting options

There are many possible uses for the Bachmann STEP power strips. For example for mounting in cable ducts, under table tops and partitions. Various mounting options are available for different applications.
