Bachmann Power Frame 4-way 2x socket 1x USB Charger 1x Custom (916.0514)
The Bachmann PowerFrame 4-way socket strip with 2x socket 1x USB Double Charger 1x Custom Module (916.0514) is specially built for the Bachmann PowerFrame mounting frame 4-fold and is easy to install. Bachmann PowerFrame, the perfect table connection field!
Bachmann POWERFRAME with aluminum profile is the compact solution for the integrated and easily accessible energy and data connection of workstations. Either for installation ex-factory or for retrofitting.
Bachmann Power Frame 4-way 2x socket1x USB Charger 1x Custom Modul 916.0514
Compact dimensions in combination with high-quality, timeless design open up Bachmann POWER FRAME 4 tray almost unlimited application possibilities even far beyond the office workplace. For example in sales rooms and shop windows, at trade fairs and at demostals. In short, wherever safe and fast connections are essential.
The fact that the selected Bachmann socket unit 916.0514 is simply inserted from below into the mounting frame, makes the thing perfect. Bachmann POWERFRAME, if the solution is to be more compact and efficient.
Key features Bachmann Power Frame 4-way socket916.0514
- Length: ca. 262 mm
- Aluminum profile anodised
- 2x protective contact socket with child protection, black, 35 ° turned
- 1x USB Dual Charger (5.2 V / 2.15 A) for charging e.g. Smartphones, tablets
- 1x Custom Module
- Power input: 0.2 m line and GST18i3 plug
Does your Bachmann PowerFrame socket strip work?
We would be happy to check if your Bachmann product is suitable for your application. Simply send us your model (manufacturer + model no.) At the end of the order process. We will then check for you whether the Bachmann socket strip fits completely and if not, we will contact you.
| Product sheet: |  [pdf, 226 kb] |
|---|---|
| Technical drawing: | [pdf, 208 kb] |
| RoHS / REACH: | [pdf] |
| Warning/safety instructions: | [pdf] |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| Number of sockets: | 2 |
| color: | Silver/Anthracite |
| USB-Charger: | USB A/A |
| Land: | Germany |
| screw-on: | No |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
