Bachmann Device supply cable earthing contact GST18 5m (375.117)
The Bachmann Device supply cable earthing contact GST18 5m (375.117) is for the Bachmann facility products (SLIDE, CONFERENCE, TOP FRAME, CONI, LIFT, POWER FRAME, DESK1, DESK2, STEP) with Wieland GST18 plug-in connectors
Bachmann Device supply cable earthing contact GST18 5m 375.117
Cables fitted with Wieland GST18 plug-in connectors are available to connect Bachmann facility products to the mains power supply. The advantages of these cables and their connectors, which are used all over the world, are flexibility in terms of length, the possibility of exchanging them should length requirements change, and availability for a variety of countries. Even extending the power supply to other power strips presents no problem and can usually be done without tools.
Key features Bachmann Device supply cable earthing contact GST18 5m 375.117
- Colour black
- Length 5m
- Cable: H05VV-F 3G 1.5 mm²
- End 1: right angle plug with earthing contact
- End 2: Wieland GST18i3 socket with 0.3 m
- 1.5 mm² green / yellow with M6 ring termination
- Pre-assembled power supply cables with integrated earth connection
- Earthing of the power strip is independent of the installation
- Ideal in combination with STEP power strips
- Table-mounted frames can be earthed independently of the power strip fitted in them
| RoHS / REACH: |  [pdf, 110 kb] |
|---|---|
| Warning/safety instructions: | [pdf] |
| Contains installation material: | + |
| Manufacturer/Importer: | Bachmann GmbH, Ernsthaldenstr. 33, 70565 Stuttgart, info@bachmann.com |
| color: | Black |
| Land: | Germany |
If warning and safety instructions are to be observed for a product, these can be found in the respective installation instructions or in a separate PDF, depending on the manufacturer. Available documents for the product can be found in the available PDF files (see above).
